Solární panely CIS - tenkovrstvé
Avancis PowerMax Smart 135 - MC4 135 Wp od 20 Ks
Obj. kód: 1990030
Značka: Avancis
Hmotnost: 19.60 kg
do 2 - 4 týdnů
Nominal rating (PMPP): 135 W
Maximum voltage: 45.6 V
Maximum power current: 2.97 A
Short-circuit current: 3.2 A
Open-circuit voltage: 61.3 V
Maximum system voltage: 1000 V
Maximum module efficiency: 12.6 %
Power tolerance: 0/+5 %
Temperature coefficident - open circuit voltage: -220 [mV / °C]
Temperature coefficident - short circuit current: 0.1 [mA / °C]
Temperature coefficident of Pmpp: -0.5 [% / °C]
Dimensions: 1595 x 684 x 37 mm
Weight: 19,6 kg
Connection type: MC4
